Description
General Introduction: In the beam transmission system, the Raytek reflector or the full mirror are used as the tail mirror and folding mirror in the laser cavity, while the mirror acts as a bending device outside the cavity.
In the laser tube, the mirror can be used as the tail mirror, and the base of the lens has a certain curvature, which plays the role of shock laser; In some laser designs, the laser reflector can change the light in the laser tube and reduce the length of the laser tube; Outside the laser tube, the reflector and the focusing mirror cooperate to form a complete optical path, which makes the design of the laser machine more space saving, and reduces the laser loss as much as possible, and keeps the working power of the laser to the maximum extent.
Products Name:
Laser mirrors/Laser reflector/Laser reflective mirror/Laser full mirrors
Alias:laser mirrors, laser reflector, laser reflective mirror, laser full mirrors, etc
Main Applying:
Main Highlights:
1).Silicon is the most commonly used substrate for mirrors. It has the advantages of low cost, strong durability and stable thermal properties.
2).Copper is usually used in high power applications due to its high thermal conductivity.
3).Molybdenum is an ideal material for various harsh physical environments because of its high surface strength. The molybdenum supplied is usually uncoated.
4).The mirror made of oxygen free copper substrate will bear extremely high laser power and can be used in industrial environment. After reasonable installation and alignment, it will provide the function of limiting diffraction focusing. Oxygen free copper mirrors have high reflectivity and a durable molybdenum coating. This makes the mirror easy to clean and adapt to harsh environment.
Main Specification:
Substrate: Silicon/Molybdenum
Unit:mm
Reflectivity(λ=10.6um) more than 98%
The listed prices are only for reference. The final price is up to the substrate type, substrate grade, product size, suface finish, surface quality and Physical & Optical request standards.
Main Cooperation Materials Manufacturers:
CORNING, OHARA, SCHOTT, LEONI, AGC,HELLMA, NIKON,VITRON,C-LASER,J-FIBER,ETC
Main Export Countries & Areas:
In the laser tube, the mirror can be used as the tail mirror, and the base of the lens has a certain curvature, which plays the role of shock laser; In some laser designs, the laser reflector can change the light in the laser tube and reduce the length of the laser tube; Outside the laser tube, the reflector and the focusing mirror cooperate to form a complete optical path, which makes the design of the laser machine more space saving, and reduces the laser loss as much as possible, and keeps the working power of the laser to the maximum extent.
Products Name:
Laser mirrors/Laser reflector/Laser reflective mirror/Laser full mirrors
Alias:laser mirrors, laser reflector, laser reflective mirror, laser full mirrors, etc
Main Applying:
| Applying 1 | Laser system |
| Applying 2 |
Laser marking machine,Laser engraving machine Laser cutting machine |
Main Highlights:
1).Silicon is the most commonly used substrate for mirrors. It has the advantages of low cost, strong durability and stable thermal properties.
2).Copper is usually used in high power applications due to its high thermal conductivity.
3).Molybdenum is an ideal material for various harsh physical environments because of its high surface strength. The molybdenum supplied is usually uncoated.
4).The mirror made of oxygen free copper substrate will bear extremely high laser power and can be used in industrial environment. After reasonable installation and alignment, it will provide the function of limiting diffraction focusing. Oxygen free copper mirrors have high reflectivity and a durable molybdenum coating. This makes the mirror easy to clean and adapt to harsh environment.
Main Specification:
Substrate: Silicon/Molybdenum
Unit:mm
Reflectivity(λ=10.6um) more than 98%
| No. | Substrate | Dia. | Edge thickness | - | - | Wavelength(um) |
| RAY-LRM01# | Silicon/Molybdenum | 12 | 3 | - | - | 10.6 |
| RAY-LRM02# | Silicon/Molybdenum | 18 | 3 | - | - | 10.6 |
| RAY-LRM03# | Silicon/Molybdenum | 19 | 3 | - | - | 10.6 |
| RAY-LRM04# | Silicon/Molybdenum | 20 | 3 | - | - | 10.6 |
| RAY-LRM05# | Silicon/Molybdenum | 25 | 3 | - | - | 10.6 |
| RAY-LRM06# | Silicon/Molybdenum | 25.4 | 3 | - | - | 10.6 |
| RAY-LRM07# | Silicon/Molybdenum | 30 | 3 | - | - | 10.6 |
| RAY-LRM08# | Silicon/Molybdenum | 38.1 | 5 | - | - | 10.6 |
| RAY-LRM09# | Silicon/Molybdenum | 50.8 | 7 | - | - | 10.6 |
| RAY-LRM09# | Silicon/Molybdenum | 200 | 15 | - | - | 10.6 |
| Other size | Customize |
|
|
|
|
|
The listed prices are only for reference. The final price is up to the substrate type, substrate grade, product size, suface finish, surface quality and Physical & Optical request standards.
Main Cooperation Materials Manufacturers:
CORNING, OHARA, SCHOTT, LEONI, AGC,HELLMA, NIKON,VITRON,C-LASER,J-FIBER,ETC
Main Export Countries & Areas:
Usa, Uk, Japan, Germany, Spain, France, Swiss, Korea, Russia, Pakistan, India, Portugal, Canada, New Zealand, Australia, Saudi Arab, Turkey, Finland, Poland ,etc.
Raytekoptics Extra value added services offered:
1). Optical workcraft & process solution design;
2). Rough processing raw materials;
3). Semi finishing raw materials;
4). Fabricate custom sizes and shapes;
5). Design and supply custom coatings;
6). Modify and resurface customer supplied materials;
7). Drill holes, notch glass and provide beveled substrates;
8). Precision polish optics with non-standard aspect ratios;
Payment Method: by T/T or Western Union.
Delivery time: 7-10 days.
Quality Warranty: Ruitaiphotoelectric(Raytekoptics) offers quality warranty for our optics products with "3R" policy. For any inferior-quality products, Ruitaiphotoelectric(Raytekoptics) is responsible for return, replacement and refund.
