Description
General Introduction: Raytek engineering scatterers can smooth and homogenize light sources with hot spots and uneven light distribution, so as to provide uniform illumination for key applications. These diffusers can efficiently and accurately distribute light to a specific cone angle...
Products Name: Quartz Engineered Diffusers
Alias: Quartz Engineered Diffusers, Engineered Diffusers, Optical Diffusers, Quartz Diffusers, Engineering Diffuser, Engineering scatterer, etc
Bandpass Filters Substrates:
Polymer-on-glass
Main Applying:
Main Characters:
1).Engineering scatterer is a plastic scatterer structure made on the surface of glass substrate. This polymer on glass structure has the characteristics of high temperature resistance and good stability of glass, as well as high damage threshold, high light transmittance, low price and accurate shape control of polymer material.
2).Precise control of beam emission pattern
3).Effective uniform light source
4).Excellent transmittance
Products Highlights:
1).Different grades materials for option.
2).High precision & high surface roughness;
3).Sizes can be customized as per the customers' request
4).Quick lead time and delivery time.
5).Matching super optics custom and processing capacity, including Moulding, CNC machining, Polishing, Particle beam processing, Magnetic flux conversion processing, Grinding, Coating, Lightweighting, Custom Shaping, Counterbores, Drilling & Coring, Edge & Bevel Polishing,3D Contouring, Bevels & Chamfers, Steps & Slots, Laser Cutting & Marking, Metrology & Inspection, Precision Pitch Polishing, Double-Sided Polishing, Optical Assembly, Measuring, etc.
6).Excellent post-sale quality warranty, with "3R"-return, replace & refund policy
Main Optical Tech Specification:
Popular Physical Size Specification:
Main Cooperation Materials Manufacturers:
CORNING, OHARA, SCHOTT, LEONI, AGC,HELLMA, NIKON,VITRON,C-LASER,ETC
Main Export Countries & Areas:
Products Name: Quartz Engineered Diffusers
Alias: Quartz Engineered Diffusers, Engineered Diffusers, Optical Diffusers, Quartz Diffusers, Engineering Diffuser, Engineering scatterer, etc
Bandpass Filters Substrates:
Polymer-on-glass
| Optional I: |
Polymer-on-glass from CORNING, OHARA, SCHOTT, LEONI, AGC,HELLMA, NIKON,VITRON,ETC |
| Optional II: |
Equivalent Polymer-on-glass Made in China, C-laser own brands |
Main Applying:
| Applying Fields I: |
Homogenizing laser beam and led Removing filament structure from extended light source The output of the fiber bundle is shaped and homogenized Remove "hot spots" from LED display Shaping and homogenizing LCD backlight output Efficient display, etc. |
| Applying Fields II: | Other |
| ***** |
|
Main Characters:
1).Engineering scatterer is a plastic scatterer structure made on the surface of glass substrate. This polymer on glass structure has the characteristics of high temperature resistance and good stability of glass, as well as high damage threshold, high light transmittance, low price and accurate shape control of polymer material.
2).Precise control of beam emission pattern
3).Effective uniform light source
4).Excellent transmittance
Products Highlights:
1).Different grades materials for option.
2).High precision & high surface roughness;
3).Sizes can be customized as per the customers' request
4).Quick lead time and delivery time.
5).Matching super optics custom and processing capacity, including Moulding, CNC machining, Polishing, Particle beam processing, Magnetic flux conversion processing, Grinding, Coating, Lightweighting, Custom Shaping, Counterbores, Drilling & Coring, Edge & Bevel Polishing,3D Contouring, Bevels & Chamfers, Steps & Slots, Laser Cutting & Marking, Metrology & Inspection, Precision Pitch Polishing, Double-Sided Polishing, Optical Assembly, Measuring, etc.
6).Excellent post-sale quality warranty, with "3R"-return, replace & refund policy
Main Optical Tech Specification:
| Tech Data | Description |
| Type | Quartz Engineered Diffusers |
| Wavelength Range | 365-1600 nm |
| Angular Deviation |
≤10°: ±0.5° >1° <10°: ±1° >10°: ±10% |
| Surface Quality | - |
| Clear Aperture | Central ≥95% of diameter |
| Damage Threshold | 0.22 J/cm2 with 10 nsec pulses at 1064 nm, typical |
| Wedge | - |
| Chamfers | - |
| Chamfers Angle Tolerance | - |
| Spot Shape: | Circle, square, rectangle, straight line,etc |
Popular Physical Size Specification:
| Size | 25.40mm, 50.8mm or custom manufacturing |
| Thickness | 0.76 mm, or design as per demand |
Main Cooperation Materials Manufacturers:
CORNING, OHARA, SCHOTT, LEONI, AGC,HELLMA, NIKON,VITRON,C-LASER,ETC
Main Export Countries & Areas:
Usa, Uk, Japan, Germany, Spain, France, Swiss, Korea, Russia, Pakistan, India, Portugal, Canada, New Zealand, Australia, Saudi Arab, Turkey, Finland, Poland ,etc.
Raytekoptics Extra value added services offered:
1). Optical workcraft & process solution design;
2). Rough processing raw materials;
3). Semi finishing raw materials;
4). Fabricate custom sizes and shapes;
5). Design and supply custom coatings;
6). Modify and resurface customer supplied materials;
7). Drill holes, notch glass and provide beveled substrates;
8). Precision polish optics with non-standard aspect ratios;
Payment Method: by T/T or Western Union.
Delivery time: 7-10 days.
Quality Warranty: Ruitaiphotoelectric(Raytekoptics) offers quality warranty for our optics products with "3R" policy. For any inferior-quality products, Ruitaiphotoelectric(Raytekoptics) is responsible for return, replacement and refund.
