Description
General Introduction: Raytek uncoated aspheric condenser is made of Schott B270 super white glass or equivalent glass. These condensers exhibit excellent transmittance in the visible to near infrared region. The surface of an aspheric condenser is molded, while a planar or spherical lens is ground and polished. The product is an ideal choice for light collection, projection, lighting, detection and concentrating applications.
Products Name: Uncoated Aspheric Condenser Lenses
Alias: Uncoated Aspheric Condenser Lenses, Uncoated Aspheric Lens, Uncoated Condenser Lenses etc.
Products Highlights:
1).Schott B270 Ultra white glass or equivalent substrate
2).Molded aspheric concentrator
3).Ground and polished spherical and flat mirrors
4).Aspheric mirror can reduce spherical aberration
5).Aspheric lens surface can reduce spherical aberration
6).High precision & high surface roughness;
7).Sizes can be customized as per the customers’ request
8).Quick lead time and delivery time.
9).Matching super optics custom and processing capacity, including Moulding, CNC machining, Polishing, Particle beam processing, Magnetic flux conversion processing, Grinding, Coating, Lightweighting, Custom Shaping, Counterbores, Drilling & Coring, Edge & Bevel Polishing,3D Contouring, Bevels & Chamfers, Steps & Slots, Laser Cutting & Marking, Metrology & Inspection, Precision Pitch Polishing, Double-Sided Polishing, Optical Assembly, Measuring, etc.
10).Excellent post-sale quality warranty, with “3R”-return, replace & refund policy
Main Tech Specification:
|
Universal Optical Character Tech Data |
|
|
Optical Lens Type: |
Aspheric Condenser Lens |
|
Lens Substrate: |
Schott B270 Ultra-White Glass or custom as per the demand of customers |
|
Surface Quality: |
80-50 scratch-dig Or custom manufacturing as per demand |
|
Coating Type: |
Uncoated |
|
Antireflection Coating Wavelength: |
Uncoated |
|
|
|
|
Size/Specification Tech Data |
|
|
Dia. |
2.0 mm 3.0 mm 4.0 mm 4.7 mm 5.42 mm 6.35 mm 6.3 mm 6.5 mm 6.8 mm 7.2 mm 9.0 mm 9.9 mm 12.0 mm 15.0 mm 20.0 mm 24.0 mm 25.0 mm 30.0 mm 32.5 mm 35.0 mm 40.0 mm 45.0 mm 50.0 mm 75.0 mm or custom manufacturing as per demand |
|
Effective Focal Length(EFL): |
2.00 mm 2.72 mm 2.75 mm 2.80 mm 2.95 mm 2.97 mm or custom manufacturing as per demand |
|
Other Available Coating Workcraft: |
Uncoated |
|
Other Available Lens Substrates: |
B270 or equivalent D-LaK D-ZK3 D-ZLaF52LA18 D-ZLaF52La9 ECO5508 L-BAL 35 (589/611)48 7980/7979/7972/7973/SQ0/1/8655/SK1300/1310 NIFS/BK7/N-SF6/N-SSK/SBL7/Zerodur/CaF2/SIC |
|
|
|
Main Cooperation Materials Manufacturers:
CORNING, OHARA, SCHOTT, LEONI, AGC,HELLMA, NIKON,VITRON,C-LASER,ETC
Main Export Countries & Areas: Usa, Uk, Japan, Germany, Spain, France, Swiss, Korea, Russia, Pakistan, India, Portugal, Canada, New Zealand, Australia, Saudi Arab, Turkey, Finland, Poland ,etc.
Raytekoptics Extra value added services offered:
1). Optical workcraft & process solution design;
2). Rough processing raw materials;
3). Semi finishing raw materials;
4). Fabricate custom sizes and shapes;
5). Design and supply custom coatings;
6). Modify and resurface customer supplied materials;
7). Drill holes, notch glass and provide beveled substrates;
8). Precision polish optics with non-standard aspect ratios;
Payment Method: by T/T or Western Union.
Delivery time: 7-10 days.
Quality Warranty: Ruitaiphotoelectric(Raytekoptics) offers quality warranty for our optics products with “3R” policy. For any inferior-quality products, Ruitaiphotoelectric(Raytekoptics) is responsible for return, replacement and refund.
